RG 6 U/4 PHY-HF (Cu/CuSn Trishield)

Categories: ,
Operating temperature -30 °C … +70 °C
Bending radius min. 10 x D
Impedance
Capacitance 52 ± 2 pF/m
Velocity of propagation %84 ± 2
Insulation resistance min. 2 G Ω x km
Operating voltage max. 1300 V
Test voltage 3000 V
Standards EN 50117, IEC 61196
Fire performans Vertical flame propagation EN 60332-1-2

Corrosive gas EN 60754-1/2

Smoke density EN 61034-2

Satellite distribution2) 2150MHz – 60m
VHF/UHF distribution3) 860MHz – 150m
S-band Cable TV distribution3) 470MHz – 210m
Attenuation @20°C max 50 MHz 4,74 dB/100m
200 MHz 9,29 dB/100m
470 MHz 14,35 dB/100m
860 MHz 19,72 dB/100m
1000 MHz 21,37 dB/100m
2150 MHz 32,52 dB/100m
2400 MHz 34,59 dB/100m
3000 MHz 39,26 dB/100m
Return Loss 5-470 MHz > 20 dB
470-1000MHz > 18 dB
1000-2000 MHz > 16 dB
2000-3000 MHz > 15 dB
Screen Attenuation 30-1000 MHz ≥ 95 dB
1000-2000MHz ≥ 85 dB
2000-3000 MHz ≥ 75 dB
Transfer Impedance 5-30 MHz ≤ 2,5 mΩ/m

Utilising physical foam insulation technology, cables have a rated impedance of 75 ohms and comply with EN 50117. They are primarily used in Cable TV, individual/central satellite distribution and CCTV security camera systems. Cables are composed of halogen-free materials (flame retardant materials that do not emit toxic gas or black dense smoke that lowers visibility). They are primarily used in highly populated areas that should have fire resistance, such as housing estates, hotels, shopping malls and smart buildings.

Conductor Electrolytic copper wire, Ø 1.02 mm (AWG18)

Insulation Physical foam PE, Ø 4.60 mm 70°C, EN 50290-2-23

Screen Al-Pet-Sy foil min. 100% coverage Tinned braided copper wire Al-Pet foil min. 100% coverage

Sheath HFFR – RAL 9011 Black, Ø 6.80 mm 70°C, EN 50290-2-27
